The hydraulic oil tank of the spreader is located in the front compartment and is installed on the wall of the front compartment, mainly for cooling and heat dissipation. The manufacturer of cement spreader trucks will explain the relevant matters to you below:
When using the hydraulic oil tank of the spreader, we should pay attention to the following points:
(1) Hydraulic oil replenishment
The hydraulic oil used in the hydraulic system is 46 # high clean, pressure resistant, and wear-resistant hydraulic oil. Special attention should be paid when adding it. The dust at the oil filling port must be cleaned and an appropriate amount should be added, not exceeding the red dot at the observation hole, to avoid overflow caused by adding too much hydraulic oil. If there is any overflow, please do not use water to clean it. You can choose to wipe and clean it.
(2) Purging of hydraulic oil tank
Due to the special working environment and high dust content, the cooling fins of the hydraulic oil tank may be contaminated with a large amount of dust, which can affect the decrease in hydraulic oil temperature and increase the operating time of the cooling fan. Therefore, the fuel tank heat sink needs to be regularly purged, and the air gun should not be too close to the heat sink during purging to avoid damaging it.
(3) Overflow pipe
The overflow pipe may overflow due to working environment or other reasons. During normal use, some workers may choose to install a bottle under the overflow pipe to maintain the cleanliness of the front compartment. At this time, special attention should be paid to the bottom of the overflow pipe not to fall into the hydraulic oil inside the bottle, to prevent the unclean hydraulic oil inside the bottle from being sucked back into the oil tank due to pressure or other reasons, which may contaminate the cleanliness of the hydraulic system, Even related vehicle malfunctions may occur.
(4) Hydraulic oil tank related connecting pipe fittings
The relevant connecting fittings of the hydraulic oil tank need to be regularly inspected to see if there is any looseness. If there is looseness, it should be re tightened in a timely manner to avoid hydraulic oil leakage.
Special attention should be paid to the fact that although the hydraulic oil tank cooling fan automatically starts to cool down, there may also be a certain amount of dust accumulation during use. The accumulation of dust can affect the heat dissipation effect of the cooling fins, as well as the opening and closing time of the fan, affecting the service life of the cooling fan.
So, the heat dissipation fins of the hydraulic oil tank radiator should be regularly purged with compressed gas. When purging, the air gun should not touch the heat dissipation fins of the radiator, and all corners should be purged. Only in this way can the ideal temperature dissipation effect be achieved and the service life of the equipment be extended. For more related matters, come to our website https://www.sddhfjx.com consulting service
