路拌机作业的程序与规程
来源:https://www.sddhfjx.com/ 日期:2023-04-24
路拌机,稳定土拌和机,是一种自行式全液压稳定土拌和设备,可对二灰土、二灰碎石、水稳沙砾等各种不同配比材料进行就地拌和,并可对旧沥青路面进行铣刨。下面冷再生机租赁厂家来讲讲路拌机作业的程序与规程事项吧。
Road mixer, stabilized soil mixer, is a self-propelled fully hydraulic stabilized soil mixing equipment that can mix various materials with different proportions such as lime soil, lime crushed stone, water stabilized gravel, etc. on site, and can also mill old asphalt pavement. Let's talk about the procedures and regulations for the safe operation of road mixers from the rental manufacturers of cold recycling machines.
(一)作业程序
(1) Operating procedures
1.检查气压表达到0.45Mpa以上时(正常值在0.6~0.8Mpa),松开停车制动器(手制动)。
1. When the air pressure is expressed above 0.45Mpa (normal value is between 0.6 and 0.8Mpa), release the parking brake (hand brake).
2.检查各仪表达到规定示值,各报警灯熄灭。
2. Check that all instruments reach the specified values and all alarm lights turn off.
3.将变速换档操纵杆拨所需位置,发动机提速1800~2000rpm,缓慢推动行走驱动手柄,将机械驶向作业地点。
3. Move the shift control lever to the desired position, increase the engine speed to 1800~2000rpm, slowly push the walking drive handle, and drive the machine towards the work site.
4.拉出前保险杠上示宽指示杆。
4. Pull out the width indicator bar on the front bumper.
5.将变速操纵杆置低速档,缓慢搬动拌和转子驱动手柄,使转子达到工作转速。
5. Set the speed control lever to low speed and slowly move the mixing rotor drive handle to reach the working speed of the rotor.
6.操纵大臂升降手柄,将拌和转子下降到要求的拌和深度。
6. Operate the boom lifting handle to lower the mixing rotor to the required mixing depth.
7.操纵尾门操纵手柄,调整尾门开启度适当位置。
7. Operate the tailgate control handle and adjust the tailgate opening to the appropriate position.
8.缓慢推动行走手柄机械达到作业行驶速度,开始拌和作业。
8. Slowly push the walking handle until the machine reaches the operating speed, and start the mixing operation.
(二)规程
(2) Safety regulations
1.制动气压低于0.45Mpa时,禁止松开手制动进入作业状态。
When the brake pressure is lower than 0.45Mpa, it is prohibited to release the hand brake and enter the operating state.
2.正常行驶用高速档,作业、大坡度爬坡或不平路行驶时,应用低速档。
2. Use high gear for normal driving, and low gear for operations, steep slopes, or uneven roads.
3.在较长距离行驶时,拌和转子大臂应提高位,并用销轴锁住。
When driving over a long distance, the mixing rotor arm should be raised to a high position and locked with a pin.
4.换档变速应停车进行。在小范围变速时,可用行走液压手柄操纵。
4. Shift and speed change should be stopped. When changing speed in a small range, it can be controlled by the walking hydraulic handle.
5.严禁不旋转拌和转子入土。
5. It is strictly prohibited to mix the rotor into the soil without rotation.
6.正常拌和作业不得随意搬动转子大臂升降手柄。
6. During normal mixing operations, it is not allowed to move the lifting handle of the rotor arm arbitrarily.
7.拌和材料中混有粒径超过40MM的石料时,禁止进行拌和作业。
7. When stones with a particle size exceeding 40MM are mixed in the mixing material, mixing operations are prohibited.
8.发现异常声响或有猛烈冲击振动时,应及时停机检查,后再作业。
8. When abnormal sounds or violent impact vibrations are found, the machine should be shut down for inspection in a timely manner, and the operation can only be carried out after resolving the issue.
9.应随时检查拌刀磨损情况,及时更换缺损拌刀,严禁缺刀作业。
9. The wear of the mixing knife should be checked at any time, and the missing mixing knife should be replaced in a timely manner. It is strictly prohibited to operate without a knife.
10.机械作业中,禁止人员上下,禁止检修作业。
During mechanical operations, personnel are prohibited from getting up and down, and maintenance operations are prohibited.
路拌机作业的程序与规程相关内容就讲解到这里了,希望您能够有所了解,更多设备事项就来我们网站https://www.sddhfjx.com咨询了解吧!
That's all for the procedures and regulations related to the safety operation of road mixers. We hope you can have some understanding. For more equipment matters, please come to our website https://www.sddhfjx.com Consult and understand!
