路面冷再生机的组成和工作原理

来源:https://www.sddhfjx.com/ 日期:2022-06-28
一般来说,长期经受重型交通的路面会出现路基损坏的情况。为了这种损坏,需要对整个路面进行结构性维修。路面冷再生机将铣刨料全部进行重新利用,加之其经济的处理方式,使得采用泡沫沥青进行冷再生施工成为一种开创性方案,达到而经济的作用。
Generally speaking, the pavement that has been subjected to heavy traffic for a long time will have subgrade damage. In order to eliminate this damage, the whole pavement needs structural maintenance. The pavement cold recycling machine reuses all milled materials, and its economic treatment method makes the use of foam asphalt for cold recycling construction a pioneering solution to achieve environmental protection and economy.
路面冷再生机的组成和工作原理
Composition and working principle of pavement cold recycling machine
组成:路面冷再生机是沥青路面冷再生施工中的主要设备,一般由动力系统、传动系统、工作装置、喷洒系统和操纵控制系统组成。
Composition: pavement cold recycling machine is the main equipment in the construction of asphalt pavement cold recycling, which is generally composed of power system, transmission system, working device, spraying system and operation control system.
工作原理:路面冷再生机向前行进时,转子向上旋转铣刨原路面材料,同时,水通过软管从路面冷再生机连接的水车中输送过来,并在路面冷再生机的拌和仓中喷洒。水的输送量通过微处理器控制的泵送系统控制,以达到需要的含水量。铣刨转子将水与铣刨料充分拌和。液体稳定剂,例如热沥青(冷再生机自带泡沫沥青发泡装置,可将热沥青加热到160-180°C,与少量水混合发泡)可通过专门设计的喷洒嘴被喷洒到拌和腔;粉状稳定剂如水泥需按设计添加量事先洒布在路面冷再生机前的路面上,路面冷再生机将粉状稳定剂与再生料和水一次性拌和。如遇再生层原级配不良的情况,可在再生前将所缺少的部分集料洒布在路面上,通过与旧料拌和来改善原路面材料的级配。
Working principle: when the pavement cold regenerator moves forward, the rotor rotates upward to mill the raw pavement materials. At the same time, water is conveyed from the water truck connected to the pavement cold regenerator through a hose and sprayed in the mixing bin of the pavement cold regenerator. The delivery volume of water is controlled by the microprocessor controlled pumping system to achieve the required water content. The milling rotor will fully mix the water with the milling material. Liquid stabilizers, such as hot asphalt (the cold regenerator has its own foam asphalt foaming device, which can heat the hot asphalt to 160-180 ° C and mix it with a small amount of water for foaming), can be sprayed into the mixing chamber through a specially designed spray nozzle; Powdered stabilizer such as cement shall be sprinkled on the road surface in front of the road surface cold recycling machine according to the designed addition amount. The road surface cold recycling machine will mix the powdered stabilizer with recycled materials and water at one time. If the original grading of the recycled layer is poor, the missing part of the aggregate can be sprinkled on the pavement before regeneration, and the grading of the original pavement material can be improved by mixing with the old material.
以上就是为大家介绍的有关冷再生机租赁的详细的介绍,希望对您有所帮助.如果您有什么疑问的话,欢迎联系我们.我们将以的态度,为您提供服务https://www.sddhfjx.com
The above is a detailed introduction about the rental of cold regenerator, which I hope will help you. If you have any questions, please contact us. We will provide services for you with a professional attitude https://www.sddhfjx.com
