A cement spreader with controllable discharge function, including a vehicle body, wherein a hopper is placed on the top outer wall of the vehicle body, and a control module is fixed on one side of the outer wall of the hopper through bolts. The control module is internally equipped with a speed sensor and display screen, and the speed sensor is connected to the vehicle control system of the vehicle body 1 through a bus. An alarm is fixed on one side of the outer wall of the hopper through bolts, The switch control end of the alarm is electrically connected to the control module, where the volume density or mass density parameters of the material to be distributed are input in advance. During operation, the speed sensor detects the driving speed of the vehicle body 1 in real time and transmits a signal to the control module. When the speed exceeds or falls below the set value, the control module 6 is electrically connected to the control alarm 14 to send an alarm, warning people, The control module performs data analysis and transmits the data to the display screen for real-time viewing by people.

粉料撒布车

Powder spreader

为了对需铺设的路面进行碾压；所述车体1的底部外壁通过螺栓固定有固定座，固定座的两侧内壁通过转轴转动连接两个滚筒，车体的一侧外壁通过螺栓固定有出料箱，料仓的底部外壁通过螺栓固定有电动伸缩板，电动伸缩板的开关控制端与控制模块电性连接，车辆行驶过程中，两个滚筒随着车辆前进在固定座2内转动，对需铺设的路面进行碾压，控制模块电性连接控制电动伸缩板的开关，使得物料通过出料箱进行出料，便于撒布作业。

To compact the road surface to be laid; The bottom outer wall of the vehicle body 1 is fixed with a fixed seat through bolts, and the inner walls on both sides of the fixed seat are connected to two rollers through rotating shafts. One side of the outer wall of the vehicle body is fixed with a discharge box through bolts, and the bottom outer wall of the material bin is fixed with a first electric expansion plate through bolts. The switch control end of the first electric expansion plate is electrically connected to the control module. During the vehicle's driving process, the two rollers rotate in the fixed seat 2 as the vehicle moves forward, Rolling the road surface to be laid, the control module is electrically connected to control the switch of the first electric expansion plate, allowing the material to be discharged through the discharge box, facilitating the spreading operation.

为了避免加料过程中粉尘飞扬；所述料仓的顶部外壁通过螺栓固定有粉料箱，粉料箱的顶部外壁通过螺栓固定有固定板，固定板的一侧外壁通过螺栓固定有弹簧，粉料箱的两侧内壁通过螺栓固定有转动轴，转动轴的圆周外壁套接有挡板，弹簧的另一端通过螺栓与挡板的顶部外壁相连接，向粉料箱内添加粉料时，粉料下沉在挡板上，弹簧弹性变形拉伸，挡板的一端受力下滑，挡板通过转动轴使得粉料箱打开一定角度进行加料，添加粉料完毕后，弹簧收缩，使得挡板一端向上回位，从而对粉料箱13进行闭合，有效避免加料过程中，粉尘飞扬引起大气污染。

To avoid dust flying during the feeding process; The top outer wall of the material bin is fixed with a powder box through bolts, and the top outer wall of the powder box is fixed with a fixed plate through bolts. One side of the outer wall of the fixed plate is fixed with a spring through bolts, and the inner walls of both sides of the powder box are fixed with rotating shafts through bolts. The circumferential outer wall of the rotating shaft is connected with a baffle, and the other end of the spring is connected to the top outer wall of the baffle through bolts. When adding powder to the powder box, the powder sinks onto the baffle, The spring deforms and stretches, causing one end of the baffle to slide under force. The baffle rotates the shaft to open the powder box at a certain angle for feeding. After adding powder, the spring contracts, causing one end of the baffle to return to its original position, thus closing the powder box 13, effectively avoiding dust flying and causing atmospheric pollution during the feeding process.

为了便于控制粉料的输入量所述粉料箱的一侧外壁开设有安装槽，料仓的顶部外壁通过螺栓固定有第二电动伸缩板，第二电动伸缩板的开关控制端与控制模块6电性连接，第二电动伸缩板的一端与安装槽相匹配，且第二电动伸缩板的顶部外壁通过螺栓固定有称重传感器，称重传感器18的型号为pts124-133g，称重传感器的信号输出端与控制模电性连接，向粉料箱内添加粉料过程中，称重传感器实时检测第二电动伸缩板上的重量变化，当达到设定值时，传递信号给控制模块，控制模块6电性连接控制第二电动伸缩板开关，使得粉料箱内的物料下滑料仓内，严格控制粉料的输入量，确保后期的水泥质量。

In order to facilitate the control of the input amount of powder, an installation groove is set on one side of the outer wall of the powder box. The top outer wall of the material bin is fixed with a second electric expansion plate through bolts, and the switch control end of the second electric expansion plate is electrically connected to the control module 6. One end of the second electric expansion plate matches the installation groove, and the top outer wall of the second electric expansion plate is fixed with a weighing sensor through bolts. The model of the weighing sensor 18 is PTS124-133g, The signal output end of the weighing sensor is electrically connected to the control module. During the process of adding powder to the powder box, the weighing sensor detects the weight change on the second electric expansion plate in real-time. When the set value is reached, the signal is transmitted to the control module. Control module 6 is electrically connected to control the switch of the second electric expansion plate, causing the material in the powder box to slide into the silo. The input amount of powder is strictly controlled to ensure the later cement quality.

为了便于向料仓内添加水；所述料仓的顶部外壁通过螺栓固定有水箱，水箱的圆周外壁通过螺栓固定有输水管，输水管的圆周外壁通过螺栓固定有电动阀门，电动阀门的开关控制端与控制模块6电性连接，料仓的一侧外壁通过螺栓固定有透视窗5，透视窗的一侧外壁粘接有刻度线，打开电动阀门，水箱通过输水管向料仓内添加水，期间，通过透视窗可以清晰了解水箱内的物料使用情况。

To facilitate the addition of water to the silo; The top outer wall of the silo is fixed with a water tank through bolts, the circumferential outer wall of the water tank is fixed with a water delivery pipe through bolts, and the circumferential outer wall of the water delivery pipe is fixed with an electric valve through bolts. The switch control end of the electric valve is electrically connected to the control module 6. One side of the outer wall of the silo is fixed with a perspective window 5 through bolts, and one side of the outer wall of the perspective window is bonded with a scale line. Open the electric valve, and the water tank adds water to the silo through the water delivery pipe, During this period, the use of materials in the water tank can be clearly understood through the perspective window.
